Laser Technology Trupulse L2 Laser Rangefinder
MPN: 7005860
Manufacturer: Laser Technology
Country Of Origin: USA
FREE SHIPPING ON ALL LASER RANGEFINDERS
Documents:
- TruPulse L2 Brochure
- TruPulse L2 Quick Reference Field Guide
- TruPulse L2 User Manual
- TruPulse L2 FAQs
The TruPulse L2 laser rangefinder is more accurate and provides calculations not found on recreational rangefinders, enabling professional results for any project.
The versatile TruPulse L2 handheld laser measures much more than just range. Measure slope distance and inclination angle and calculate horizontal distance, vertical distance, height, and 2D vertical missing line values. This laser rangefinder is more accurate and provides calculations not found on recreational rangefinders enabling professional results. Take advantage of Laser Tech’s four Advanced Targeting Modes (Closest, Farthest, Continuous and Filter) and TruTargeting technology so you know exactly what accuracy level is being achieved.
Key Features:
- Measurement | Provides measurement capability with distance & inclination values.
- TruTargeting | Faster acquisition and greater accuracy mean confidence, efficiency, and safety. Physical, visual, and audible feedback confirm target acquisition.
- Targeting Mode | Advanced targeting modes (Closest, Farthest, Continuous, and Filter).
- Ergonomics | Easy to hold, lightweight, rubberized grips, tactile button feedback.
- Rugged | Withstands harsh conditions with rugged, waterproof housing. Holds up to everyday uses under any conditions and is completely dust and waterproof.
- On Board Calculations | Auto calculates horizontal distance, vertical distance, height, and 2D missing line values.
- UI / Display | Icon-driven display with 100% automatic brightness adjustments.
- User Experience | 5 Intuitive User Interface and workflows.
Trupulse L2 Specifications:
|
Distance Accuracy to Typical Targets |
+/- 0.5m (1.6 ft) |
|
Distance Accuracy to Weak Targets |
± 1 m (3 ft) |
|
Max Range to Reflective Targets |
2195 m (7200 ft) |
|
Max Range to Non-Reflective Targets |
1200 m (3900 ft) Typical |
|
Minimum Range |
5m (16 ft) |
|
Target Acquisition |
0.5 Seconds |
|
Inclination Accuracy |
± 0.5° Relative |
|
Inclination Limits |
± 90° |
|
Range Display Resolution |
High Accuracy: 0.1m (0.5 ft) Low Accuracy: ± 1m (3 ft) |
|
Inclination Resolution |
0.5 degree, 0.5% Slope |
|
Scope Magnification / In-Scope Display Type |
Optics: 5X magnification; PDLC Display, AUTOMATIC BRIGHTNESS DISPLAY, Display Color: Black/Red |
|
Battery Type |
One CR2; 10 hours continuous use |
|
Waterproof / Environmental |
Environmental Rating IP67: Water & Dust Proof |
|
Temperature |
Operational temperature -5 to 60 °C (23 to 140 °F); Storage -25 to 60 °C (-13 to 140 °F) |
|
Shock Resistance |
Drop test 4 feet to 3 inches deep sand |
|
Vibration resistance |
JIS A |
|
Size |
height: 75mm width: 47mm length: 110mm |
|
Weight |
227 grams (8 oz) |
|
Regulatory Certifications |
FDA; FCC; CE; IEC; RoHs; REACH, WEEE |
|
Eye Safety |
FDA CLASS 1 LASER PRODUCT: Product complies with IEC60825-1 Ed. 3:2014-5 and 21CFR1040.10/11 per Notice 50:2007 |
|
Warranty |
2 year |
FAQ
What is the maximum range of the TruPulse L2 laser rangefinder?
The TruPulse L2 has a maximum range of 2,000 meters (6,562 feet) to a reflective target.
What is the accuracy specification of the distance measurements?
The distance measurement accuracy is +/- 1 meter for distances up to 500 meters, and +/- 2 meters for distances from 500 to 2,000 meters.
Does the TruPulse L2 measure heights and vertical angles?
Yes, the TruPulse L2 can measure height, vertical angle, and slope distance with a single pull of the trigger.
What is the maximum slope distance measurement capability?
The TruPulse L2 can measure slope distances up to 2,000 meters (6,562 feet).
What power source does the TruPulse L2 use?
It is powered by a rechargeable lithium-ion battery pack.
How long does the battery last on a single charge?
The battery life is rated for approximately 8 hours of continuous use.
What are the environmental operating specifications?
The TruPulse L2 can operate in temperatures from -20°C to 60°C (-4°F to 140°F).
Does it have any data storage capabilities?
Yes, the TruPulse L2 can store up to 1,000 data points internally.
What are the dimensions and weight of the unit?
The dimensions are 5.8 x 3.7 x 3.5 inches (14.7 x 9.4 x 8.9 cm), and the weight is 0.77 lbs (0.35 kg).
Is the TruPulse L2 waterproof or water-resistant?
The unit is water-resistant and rated IP54 for protection against dust and water splashing.
